Our assortment

Flat Products
Sheets

From the very beginning, our company operates in the field of ferrous metallurgy. Our assortment fully follows the metalworking industry, and in our warehouses you can find a rich assortment of all types of ferrous and non-ferrous metallurgy goods.
You can find our complete range of products on this page.

Hot rolled sheets

HOT ROLLED SHEETS

Hot-rolled sheets are intended for further processing by cold forming, and are directly used in the pipe industry, for the production of profiles, packaging... They are used in various segments of industry and construction: in the industry of machines, vehicles, structures in shipbuilding, production of industrial equipment, in metalworking.

THICKNESS	MASS	DIMENSIONS (WxL) mm MASS Kg
(s)mm	KG/m2	1000 x 2000	1250 x 2500	1500 x 3000	1500 x 6000	2000 x 6000
1.50	11.78	23.56	36.81	-	-	-
2.00	15.70	31.40	49.06	70.65	141.30	-
2.50	19.62	39.24	61.31	88.29	176.58	-
3.00	23.55	47.10	73.59	105.98	211.96	282.60
4.00	31.40	62.80	98.13	141.30	282.60	376.80
5.00	39.5	78.50	122.66	176.63	353.26	471.00
6.00	47.10	94.20	147.19	212.00	424.00	565.20
7.00	54.95	109.90	171.72	247.00	494.00	659.40
8.00	62.80	125.60	196.25	283.00	566.00	753.60
9.00	70.65	141.30	221.00	318.00	636.00	847.80
10.00	78.50	157.00	245.00	353.00	706.00	942.00
12.00	94.20	188.40	294.00	424.00	848.00	1130.40

THICKNESS	MASS	DIMENSIONS (WxL) mm MASS Kg
(s)mm	KG/m2	1500x6000	2000x6000	2500x6000	2000x8000	2500x8000
5	39.25	353	471	589	628	785
6	47.10	424	565	707	754	942
7	54.95	495	659	824	879	1099
8	62.80	565	754	942	1005	1256
9	70.65	636	848	1060	1130	1413
10	78.50	707	942	1178	1256	1570
12	94.20	848	1132	1413	1507	1884
14	109.90	989	1319	1649	1758	2198
15	117.75	1060	1413	1766	1884	2355
16	125.60	1130	1507	1884	2010	2512
18	141.30	1272	1696	2120	2261	2826
20	157.00	1413	1884	2355	2512	3140
22	172.70	1554	2072	2590	2763	3454
25	196.25	1766	2355	2944	3140	3925
28	219.40	1978	2638	3297	3517	4396
30	235.50	2120	2826	3533	3768	4710
35	274.75	2473	3297	4121	4396	5495
40	314.00	2826	3768	4710	5024	6280
45	353.25	3179	4239	5299	5652	7065
50	392.50	3533	4710	5888	6280	7850
60	471.00	4239	5652	7065	7536	9420
70	549.50	4945	6594	8242	8792	10990
80	628.00	5652	7536	9240	10048	12560
90	706.50	6358	8478	10597	11304	14130
100	785.00	7065	9420	11775	12560	15700

Cold rolled sheets

COLD ROLLED SHEETS

Cold-rolled sheets of low-carbon steel are suitable for cold forming, welding and coating (painting, varnishing, plasticizing).

DEBLJINA	TEŽINA	DIMENZIJE (WxL) mm TEŽINA Kg
(s)mm	KG/m2	1000x2000	1250x2500	1500x3000
0.40	3.140	6.28	9.81	14.13
0.50	3.925	7.85	12.27	17.66
0.60	4.710	9.42	14.72	21.20
0.70	5.495	10.99	17.17	24.73
0.80	6.280	12.56	19.63	28.26
0.90	7.065	14.13	22.08	13.78
1.00	7.850	15.70	24.53	35.33
1.25	9.810	19.62	30.66	44.15
1.50	11.780	23.56	36.81	53.01
2.00	15.700	31.40	49.06	70.65
2.50	19.620	39.24	61.31	68.29
3.00	23.550	47.10	73.59	105.98

Hot rolled ribbed sheets

HOT ROLLED RIBBED SHEETS

They are produced from general structural and low-carbon steels. Ribbed sheets on one surface have ribs formed by rolling in the form of rhombuses or tears, and the other surface is smooth.

DEBLJINA	TEŽINA		DIMENZIJE (WxL) mm TEŽINA Kg
(s)mm	KG/m2		1000x2000		1250x2500		1500x3000
	TEAR.	CHEQU.	TEAR.	CHEQU.	TEAR.	CHEQU.	TEAR.	CHEQU.
2.00	17.70	-	35.40	-	55.31	-	79.65	-
2.50	21.63	23.63	43.26	47.26	67.59	73.84	97.33	106.34
3.00	25.55	27.55	51.10	55.10	79.59	86.09	114.97	123.98
4.00	33.40	35.40	66.80	70.80	104.38	110.63	150.31	159.30
5.00	41.25	43.25	82.50	86.50	128.91	135.16	185.63	194.63
6.00	49.10	51.10	98.20	102.20	153.44	159.69	220.95	229.95
8.00	64.80	66.80	129.60	133.60	202.50	208.75	291.60	300.60
10.00	90.50	92.50	181.00	185.00	282.81	289.06	407.25	416.25

HOT ROLLED SHEETS FOR BOILERS AND PRESSURE VESSELS

EN 10027-1	DIN 17155	JUS C.B4.014*
P 235 GH	H I	Č 1202
P 265 GH	H II	Č 1204
P 295 GH	17 Mn 4	Č 3133
P 355 GH	19Mn 6	/
16 Mo 3	15 Mo 3	Č 7100
13 CrMo 4-5	13 CrMo 4 4	Č 7400
10 CrMo 9-10	CrMo 9 10	Č 7401
11 CrMo 9-10	/	/

ASORTIMAN TOPLO VALJANI KOTLOVSKIH LIMOVA

/		DEBLJINA U MM		ŠIRINA U MM		DUBINA U MM		MASA PAKETA U T		UNUTRAŠNJI PRESEK KOTURA U MM
TABLE		3.00-6.00		do 1500 (2000)		do 10.000		8		/
ŠIROKE TRAKE U KOTURU		3.00-6.00		do 1500 (2000)		do 10.000		8		/

HOT ROLLED SHEETS IN QUALITY

QUALITIES
EN			JUS
C45/C45E			Č1530/Č1531
C60/C60E			Č1730/Č1731
42CrMo4			Č4732
50Mn7			Č3134
C75			Č1832
50CrV4/51CrV4			Č4830/Č4831

QUALITY	THICKNESS (MM)
	2.00	3.00	3.5	4.00	5.00	5.5	6.00	7.00	8.00	10	12	15	16	18	20	25	30	35	40	45	50
C45		X									X	X	X	X	X	X	X	X	X	X	X
C60		X	X	X	X	X	X	X	X	X	X
42CrMo4									X	X	X	X			X	X	X	X	X	X	X
50Mn7		X		X	X		X		X	X	X	X			X	X	X		X		X
C75		X
51CrV4		X		X	X		X	X	X		X
HAR40									X	X	X	X			X	X	X

QUALITY	THICKNESS (MM)
	55	60	70	80	90	110	120	130	135	140	150	160
C45		X	X	X	X	X	X	X	X	X	X	X
C60
42CrMo4	X	X	X	X	X	X
50Mn7		X
C75
51CrV4
HAR40

GALVANIZED SHEETS

Due to their high resistance to corrosion, they are widely used in various industrial branches. They are used in construction, for the production of elements for roofs and facades, panels for walls and roofs, in air conditioning, for ventilation ducts and air conditioners, in the automobile industry, the industry of agricultural machinery, for the production of silos, various parts of appliances.

THICKNESS	LENGTH
	1000	1250	1500
0.45	X	X
0.5	X	X
0.6	X	X
0.7	X	X
0.8	X	X
0.9	X	X	X
1.0	X	X	X
1.2	X	X	X
1.5	X	X	X
2.0	X	X	X
2.1	X	X	X
2.2	X	X	X
2.3	X	X	X
2.4	X	X	X
2.5	X	X	X
2.6	X	X	X
2.7	X	X	X
2.8	X	X	X
2.9	X	X	X
3.0	X	X	X

GALVANIZED PREPAINTED SHEETS (PPGI)

GALVANIZED PREPAINTED SHEETS(PPGI)

Under construction.

ALUMINUM SHEETS

ALUMINUM SHEETS - FLAT
Aluminum strips and sheets are widely used in the metal processing industry, construction, and packaging industry.

ALUMINUM SHEETS FLAT
MEASURES	DIMENSIONS IN MM
THICKNESS	0.5-6.00
WIDTH	1000-1500
LENGTH	2000-3000 or as customer desires

ALUMINUM SHEETS RIBBED
Ribbed aluminum sheets have embossed patterns on both surfaces.

ALUMINUM SHEETS RIBBED
MEASURES	DIMENSIONS IN MM
THICKNESS	2.00-6.00
WIDTH	600-1500
LENGTH	1400-3000 or as customer desires

PROCHROME (INOX) SHEETS

In preparation

Perforirani limovi

PERFORATED SHEETS

They are widely used in construction, industry, design, acoustics... We produce perforated sheets at order, choosing materials of different shapes, diameters and dimensions.

Flat Products - Sheets
